SUP-ADI3050 Ammonia Nitrogen Electrode

The SUP-ADI3050 is an eco-friendly, real-time online ammonia nitrogen electrode with automatic pH/temperature compensation, RS485 output, and Modbus support, ideal for diverse water quality monitoring applications.

Characteristics

No Reagent Required, Eco-friendly and Pollution-free Operation

Direct Measurement of Ammonium Ions Without Expensive Sample Pre-treatment

Automatic pH and Temperature Compensation for Enhanced Accuracy Across Various Conditions

Standard Equipped with Ammonium Ion Electrode, pH Electrode, and Reference Electrode (Potassium Ion Optional)

Wide Measuring Range: 0-100mg/L (WV), 0-1000mg/L (WX)

Designed for Diverse Water Quality Monitoring Applications Including Surface Water, Sewage Water, Tap Water, Reservoirs,

Drinking Water, Natural Water, and Domestic Sewage

Specification	Detail
Measurement Range	0-100 mg/L \| 0-1000 mg/L
Output Protocol	RS485 (Modbus RTU)
Power Supply	12VDC (9-24VDC compatible)
Cable Options	Standard: 10m/20m/30m \| Custom: ≤100m
Construction	POM/316LSS Housing \| NPT 3/4 Thread

SUP-ADI3050 Online Ammonia Nitrogen Electrode

The SUP-ADI3050 Ammonia Nitrogen Electrode is a real-time monitoring solution designed for precise ammonia-nitrogen detection in water environments. This eco-friendly sensor eliminates the need for chemical reagents, offering a pollution-free and cost-effective alternative to traditional methods.

Key Features:

Direct immersion design with no sample pretreatment
Automatic pH/temperature compensation for accuracy
Modbus RS485 output for seamless system integration
Corrosion-resistant construction for long-term reliability

Widely applicable in surface water, sewage systems, drinking water, and industrial wastewater monitoring. The modular design allows easy electrode replacement, reducing downtime and maintenance costs.

*Ideal for environmental protection agencies, water treatment facilities, and industrial process monitoring applications.
